STMicroelectronics (Switzerland) has introduced a series of low-RDS(on) MOSFETs made with its new Smart STripFET F8 technology, which is engineered for optimum conduction performance and small die size. The devices target space-constrained applications including power distribution and battery management in automotive products.
The first device in the new series, the STL059N4S8AG, is a 40V/420A N-channel enhancement-mode MOSFET with RDS(on) 0.59mΩ, housed in a PowerFLAT 5x6 package. The compact outline saves PCB space, easing the design of smaller control modules, while high thermal conductivity and efficient dissipation help meet stringent reliability targets.
Additional features include:
- An extended maximum operating temperature of 175°C.
- Availability as an AEC-Q101 qualified part in a package with wettable flanks that facilitates optical inspection in automotive assemblies.
- New F8 technology with a modified trench gate that enhances on-state performance and silicon-area efficiency.
- Optimized for applications where minimizing conduction losses is key to improving overall efficiency.
- Well suited for high-current power distribution, where the devices combine effectively with STi²Fuse VIPower gate drivers that offer tunable circuit breaking to safeguard PCB traces, connectors, and wiring.
In automotive applications, Smart STripFET F8 MOSFETs deliver more of the battery’s energy to on-board electrical systems while reducing power dissipation, thereby contributing to extended driving range, according to the company.
In a battery-management system (BMS), where the main functions are monitoring cell states, balancing, and protection, the MOSFETs’ lower RDS(on) enhances efficiency during battery charging and discharging.
The STL059N4S8AG is in production now, in automotive grade.
For more information, visit: https://www.st.com/smart-stripfet-f8.
