Nidec-U.S. Motors launches New PrecisionFlow Motor

The new PrecisionFlow Motor offers efficiency through integrated electronics.

The new Nidec PrecisionFlow motor.
The new Nidec PrecisionFlow motor.
Nidec

Nidec Motor Corporation introduces a new electronically commutated motor (ECM) that offers up to 85 percent efficiency, an improvement of up to 30 percent over common PSC motors, the PrecisionFlow motor.

PrecisionFlow motor features:

  • Up to 85% efficient, 30% better than common PSC motors.
  • Robust, integrated electronics with advanced thermal and overload protection.
  • Range of analog inputs and controls: (10-0V), (0-10V), and RS-485.
  • 3 DIP switches allow field configuration: CW/CCW, speed/torque mode and external or on-board potentiometer.
  • Advanced programming software reduces development and testing.

Specifications:

  • Horsepower: 1/3, 1/2, 3/4, 1 HP
  • Voltage: 1Ø, 115/208 – 230/277 Volts
  • Speeds: 1200 and 1800 RPM
  • Inputs: 0-10V, 10-0V, RS-485, or control via on-board or remote potentiometer
  • Operation Modes: Constant Torque, Constant Speed
  • Frame: NEMA 48
  • Enclosure: Totally Enclosed Air Over (TEAO) or Open Air Over (OAO)
  • Efficiency: Good = 80%, Better = 82%, Best = 85%
  • Mounting: Stud, Rigid Base or Belly-Band mounting available

For more information, visit acim.nidec.com.
